General Information

GD6000A is designed to measure the capacitance and dielectric loss factor (tgδ) of electric equipment. It can test grounded equipment, ungrounded equipment, completely-sealed CVT (Capacitive Voltage Transformer), dielectric loss of insulating oil and standard capacitors. It generates the testing voltage by itself, and the frequency is 45-55Hz(or 55-65Hz) to avoid the electromagnetic interference from power frequency, in order to ensure the measuring accuracy.

Features

• 106*55 LCD display.
• Automatical measurement by microcomputer, simple and accurate.
• Non-power frequency testing method, to ensure accuracy. Multiple modes for testing,
• High capacity of data storage. Test data are saved in time sequence, which can be viewed or exported via U disk.
• Convenient for CVT testing, which tests C1 and C2 simultaneously. CVT transformation ratio and voltage angle difference can be tested as well.
• High speed of sampling, ensured by digital controlled inverter and sampling circuit.
• Multiple protection functions to guarantee safety.

Technical parameters

• High Voltage Output: 0.5 ~ 10kV;
• Capacity: 1500VA
• Accuracy: tgδ: ± (1.0% of the reading +0.04%),Cx: ± (1.0% of the reading+5PF)
• Resolution: tgδ: 0.01% Cx: 1pF;
• Measuring range: 0.1% < tgδ<50%
• 3PF < Cx <60000PF
• 10kV, Cx ≤ 30000PF
• 5kV, Cx ≤ 60000PF;
• Power Supply: AC 220V ± 10% 50 ± 1Hz;
• Harmonic meet: ≤ 3%;
• Conditions of use: -15 ℃ -50 ℃ Humidity <80%;
• Dimensions: 460 (L) × 335 (W) × 340 (H);
• Weight: 30 kg;
