What can AC resonance do?

AC resonant test system is designed for AC withstand voltage test of 6kV-500kV electrical transformer, substation capacitive equipment (such as GIS, switch, busbar, bushing, CT/PT), 6kV-220kV high voltage cable, motor/generator(input voltage is 20kv or below), as well as the calibration test of CVT boosting (with voltage level 35kV、66kV、110kV、220kV、330kV、500kV)





  For substation                          For generator                                For CVT                                For cable



AC resonant test system  VS AC/DC hipot test set	Meet testing requirements of large capacity test objects; Its volume and weight are smaller than power frequency withstand voltage, easy to be carried;
AC resonant test system  VS  VLF AC hipot test set	VLF is mainly specific to 10kv/35kv cables, while AC resonant is suitable for 10/35/110/220kV cables, main transformer, generator, CVT, switch and so on.
AC resonant test system  VS  DC hipot test set	DC hipot test set: direct current is input; AC resonant test system: alternating current is input.



How to choose suitable AC resonant test system?

The following technical parameters should be provided for the choice of suitable AC resonant test system:

• Electrical transformer: voltage level (for example:10/35/110/220kV); Max capacity; testing property ( neutral point withstand voltage or full insulation withstand voltage); single phase ground capacitance;
• Electrical cable: voltage level (for example, 10/35/110kV) ; Max. Length; section surface;
• Generator, motor: voltage level (output voltage or called working voltage); testing voltage (the highest withstand voltage value); single phase ground capacitance range (for example,0.2-0.55uF etc. )
• GIS: voltage level (or called working voltage); testing voltage (the highest withstand voltage value); interval number;
• Switch, insulator, PT, CT, insulation test set, busbar : voltage level (or called working voltage); testing voltage (the highest withstand voltage value);
• CVT calibration: voltage level (or called working current, such as 35/110/220kv);testing voltage (the highest withstand voltage value); capacitance range (for example, 0.005-0.02uF etc.)
